P1.8mm GOB Technology Indoor LED Display SMD1515 High-Definition Large Video Screen Wall
1.875mm small pixel pitch LED display, 800nits+ brightness, 3840Hz+ refresh rate, HD video wall
- Indoor high-definition LED video screen
- Lightweight die-casting aluminium LED cabinet
- Indoor top-level SMD1515 LED lamp
- High refresh MBI5153/CH2153 driving IC
- Advanced GOB SMD technology
- 4K, 8K resolution support easily
Silu`s P1.8mm GOB Technology Indoor LED Display is a kind of smaller pixel pitch LED video wall display with a narrow 1.8mm LED pixel pitch, it is a high-definition LED video screen wall with a very close viewing distance less than 1.8meter.
Our P1.8mm high-definition video wall LED panel is a member of Silu`s fine-pitch LED video walls available in 0.9, 1.2 and 1.5 millimetres pitches, but popular selling for the interactive LED visualization product market, the P1.8mm GOB SMD technology large video screen wall is a completely seamless interactive SMD1515 LED video wall solution for any indoor occasions.
The GOB technology P1.8mm SMD1515 HD LED display is designed and produced for the high-end market users with GOB protection for the SMD LED lamps against damage, it is a real ultra high-definition and can be easy to mount an industry-leading 2k, 4k, even 8k resolution screen wall.
P1.8mm GOB Technology Indoor LED Display LED Module Configuration
- Famous Nationstar/Cree*/Nicha* SMD LED Lamps
- 4-Layer Gold-Plated Circuit Board
- MBI5153/CH2153 High Refresh Driving ICs
- COB Technology Mask LED Module
- Front and Back Access*
P1.8mm GOB Technology Indoor LED Display LED Cabinet Configuration
- Die-casting Aluminium Lightweight LED Cabinet
- A 16:9 Ratio Rate LED Video Wall Screen Unit
- Famous Meanwell 5V40A Power Supply
- Nova or Colorlight Receiving Card* (Option)
- Signal & Power Integration Interfaces
P1.8mm GOB Technology Indoor LED Display Description
Silu`s P1.8mm GOB Technology Indoor LED Display brings high-resolution images to indoor applications by providing stunning image quality with precise colours, it creates exceptional visual experiences that stay constant over time and no image tearing or video hiccups occur as the video is smoothly synchronized.
With design principles gained from Silu`s learnings from the world's leading install base of fine pitch LED video wall, the P1.8mm GOB Technology Indoor LED Display is the better LED video wall solution to feature an innovative "flat panel" design. With a slim type LED cabinet and the finest pixel pitches, P1.8mm GOB Technology Indoor LED Display delivers the pixel density and form-factor to match LCD and Rear projection video walls, but with a truly seamless video wall configuration of any size.
Our P1.8mm GOB Technology Indoor LED Display LED screen comes with a 16:9 form factor optimized for the most popular high resolutions, ease of installation and service, and outstanding flatness and uniformity. The P1.8mm smaller pixel pitch indoor LED panel is self-contained with standard HDMI inputs and looping, along with optional redundant configurations. Larger LED display wall means fewer displays are needed to create a video wall, reducing potential points-of-service.
High Refresh Rate and Superior Image Quality
Silu`s P1.8mm indoor GOB Technology LED Display Screen is made for high-end markets with high refresh rate, excellent grey level and high contrast ratio, which ensuring to fulfil the clients` requirements on the brightness and colour uniformity and fidelity, it delivers superior image quality all times.
Wide Viewing Angle and Perfect Visual Effect
The P1.8mm GOB Technology Indoor LED Display LED screen has a more than 160°super wide horizontal and vertical viewing angle covers more potential customers. The broadcasting pictures are stable with no scanning line, and the edge of the image is sharp and clear when dealing with dynamic pictures.
Seamless Assembly and Lightweight
With CNC processing, the range of tolerance is controlled within 0.1mm that guarantees the seamless assembly and perfect performance is presented. The lightweight die-casting aluminium LED panel makes it easy to transport and it`s labour-saving, very high efficiency and cost-effective.
Convenient Front/Rear Installation and Maintenance
Our P1.8mm GOB Technology Indoor LED Display LED screen is as quick as block-building. It can be accessed both from the front and rear installation with a cabinet thickness of only 80mm. Additionally, module, power supply, receiving card, conversion card and cables between panels can all be maintained quickly from the front without professional skills.
Enhanced Power Efficiency
The P1.8mm GOB Technology Indoor LED Display LED screen delivers advanced power efficiency based on the proprietary driver, controller and LED module design to extend the life of the product by providing highly uniform colour and brightness while reducing heat emission, climate control requirements and power consumption.
Intelligent System and Stable Operation
Calibration data retrieval function and worry-free parameter back-up function are both embedded in every smart module. Besides, power system, temperature and other working status are automatically monitored to achieve intelligent management. Silu`s AC-DC and DC-DC power schemes are both available to ensure safe and reliable operation of the small pixel pitch LED screen wall, surely no sudden shut-down will occur during use.
This P1.8mm GOB Technology Indoor LED Display LED screen can be used in a variety of application occasions, for example, lighting shows, concerts, wedding, events, shopping malls, entertainment and sport venues, schools, government, trade fair, exhibition, press conference, meeting rooms, cinemas, airports, hotels, station, stadium and variety of public places.
Other Key Benefits
- Excellent image quality, wide viewing angles
- Lowest weight in its class
- Minimum installation costs
- Simple precision supporting steel required
- Ultimate excellent and reliability
- Rental and fixed indoor installation
- Advanced web-based setup, monitoring and control
P1.8mm GOB Technology Indoor LED Display Specification
P1.8mm Indoor GOB LED Display Pixel Pitch 1.875mm LED Brand Nationstar or Cree* or Nichia* Pixel Configuration 1R1G1B Pixel Density 284,444 Pixels/m² LED Module 300mm x 168.75mm (11.81" x 6.64") 160 pixels x 90 pixels LED Cabinet 600mmx337.5mm (23.62"x13.29") (320 pixels x 180 pixels) Material: Aluminum Steel: / Aluminum: < 8Kg(< 17.6 Lbs) Working Voltage AC220V±10%; AC110V±10% Power Consumption Average 280W/m² / Max 880W/m² Maximum Brightness > 800 cd/m² Refresh Frequency > 3840Hz/S Change Frame Frequency 60Hz~ >60Hz Drive Mode 1/30 Scanning Total Colors 281 Trillion Colors Grade Level RGB 65536 Grade Best Viewing Distance 1m~>30m (3ft~>90ft) Best Viewing Angle Horizontally 160° / Vertically 160° Screen Lifetime > 100,000 hours Protection Level Front IP43 Control System ¹ Simple LED Video Control System or Advanced LED Video Processor Ambient Temperature -40°C ~ 60°C (-30°F ~ 150°F) Relative Humidity 10%~90% Input Signal RF S-Video RGB RGBHV YUVYC etc. Brightness Adjustment 256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit) Package Material Wooden Case / Flight Case Warranty ³ 2 Years (3 Years for Cree and Nichia)
- WIFI/LAN/WAN/3G/WIMAX control system is available upon request.
- The intelligent multifunctional card is available with an automatic brightness sensor to save energy including an outside temperature sensor.
- Three years warranty extension program available for Narrow Pixel Pitch P1.8mm GOB Technology Indoor LED Display.
